지LA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
주요 특징
Stainless steel structure；Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
무게 피드백 및 비례 트랙은 다양한 재료의 다양한 비율에 대한 다양한 포장 된 중량의 부족을 제거합니다.
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Datㅏ
| Hopper | Quick disconnecting hopper 25L |
| 포장 중량 | 10 - 1000g |
| 포장 정확도 | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
| 충전 속도 | 5 – 20 times per min |
| 전원 공급 장치 | 3P AC208-415V 50/60Hz |
| 총 출력 | 2.25Kw |
| 총 무게 | 350kg |
| Overall Dimensions | 1205×1010×2174mm |
